GM 19177257, 25178731, 25315277, 25320515, 19331280, 9535035 Electric Fuel Pump Assembly

Description Fuel Pump Module Assembly
Gaskets Included Yes
Height (in) 13.7
Max Pressure Range (Psi) 123.3
Max Free Flow (Gph) 57.7
Resistance Empty (Ohms) 39
Resistance Full (Ohms) 250
Rheostat Range (Ohms) 39-250
Inlet Quantity 1
Inlet Type Quick Connect
Inlet Diameter (IN) 5/16
Outlet Quantity 1
Outlet Type Quick Connect
Outlet Diameter (IN) 3/8
Compatible Fuels Gas
Wiring Harness Included Yes
Hardware Included Yes
Min Free Flow Rate (Gph) 48
Min Pressure Range (Psi) 78
Strainer Included Yes
Pin Count 4
Pin Shape Flat
Connector Shape Oval
Connector Gender Male
Inline Pump No
In Tank Yes
Negative Ground Yes
Pump Type Turbine
Volts 12 vDC

GM 19177257, 25178731, 25315277, 25320515, P459M, 19331280, 9535035,

SPECTRA PREMIUM SP459M
DENSO 9530017
BOSCH 67358
DELPHI FG0071
AIRTEX E3953M
CARTER P74789M
ACDELCO MU1772

CHEVROLET BLAZER 1997-1998
GMC JIMMY 1997-1998
OLDSMOBILE BRAVADA 1997-1998
