TOYOTA 230200A010, 232170C010, 2321903010, 232210A040, 232490A020, 233000A020 Electric Fuel Pump Assembly

Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 7.5
Max Pressure Range (Psi): 50
Max Free Flow (Gph): 51
Resistance Empty (Ohms): 260
Resistance Full (Ohms): 25
Rheostat Range (Ohms): 260-25
Outlet Quantity: 1
Outlet Type: Push In
Outlet Diameter (IN): 5/16
Compatible Fuels: Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 42
Min Pressure Range (Psi): 44
Strainer Included: Yes
Pin Count: 5
Pin Shape: Flat
Connector Shape: Trapeze
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC

230200A010, 232170C010, 2321903010, 232210A040, 232490A020, 233000A020, 7702406020, 7716933020, 7717507020, 7724102010, 7778506020, 8332006010, 9015950352, 90159A0022,

SPECTRA PREMIUM SP9026M

TOYOTA AVALON 2002-2004
