DELPHI FG2202, MERCEDES-BENZ 9064708094, 906-470-80-94 Electric Fuel Pump Assembly

DELPHI FG2202, MERCEDES-BENZ 9064708094, 906-470-80-94 Electric Fuel Pump Assembly

DELPHI FG2202, MERCEDES-BENZ 9064708094, 906-470-80-94 Electric Fuel Pump Assembly
FPM2139 MERCEDES-BENZ Electric Fuel Pump Assembly
Vapor Pressure Sensor No
Fuel Level Sender Assembly Included Yes
System Pressure 70 psi
Package Contents Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet
Outlet Outside Diameter (in) 0.375
Voltage (2H) 12.0
Fuel Type Diesel
Regulator Included Yes
Maximum Pressure (PS) 90.0
Terminal Type Blade
Gasket or Seal Included No
Terminal Quantity 4
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 3
In Tank or External In Tank
Resistance Ohms Empty 873.0
Resistance Ohms Full 51.0
Internal Or External Strainer Internal
Average Current Draw (A) 10
Average Flow Rating (GP) 49
Pump Type Electric
9064708094,
DELPHI FG2202
MERCEDES-BENZ SPRINTER 2500 2014-2016
MERCEDES-BENZ SPRINTER 3500 2014-2016
