HYUNDAI 31120D3500, 31120-D3500, 31370C3000, 94460D3500 Electric Fuel Pump Assembly

HYUNDAI 31120D3500, 31120-D3500, 31370C3000, 94460D3500 Electric Fuel Pump Assembly

HYUNDAI 31120D3500, 31120-D3500, 31370C3000, 94460D3500 Electric Fuel Pump Assembly
FPM2156 HYUNDAI Electric Fuel Pump Assembly
Vapor Pressure Sensor Yes
Fuel Level Sender Assembly Included Yes
Package Contents Fuel Pump Module Assembly w/Float Arm, Instruction Sheet
Outlet Outside Diameter (in) 0.313
Voltage (2H) 12.0
Fuel Type Gas
Regulator Included Yes
Terminal Type Blade
Gasket or Seal Included No
Terminal Quantity 9
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 2
In Tank or External In Tank
Resistance Ohms Empty 200.0
Resistance Ohms Full 15.0
Internal Or External Strainer Internal
Average Current Draw (A) 10
Pump Type Electric
31120D3500, 31370C3000, 94460D3500, 9446 0D350 0,
DELPHI FG2113
HYUNDAI TUCSON 2016-2019
KIA SPORTAGE 2016-2018
