FORD F2GZ9H307A, F2GZ-9H307-A, F2GZ9H307G, F2GZ-9H307-G Electric Fuel Pump Assembly

System Pressure 51 psi
Fuel Level Sender Assembly Included Yes
Vapor Pressure Sensor No
Package Contents Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet
Outlet Outside Diameter (in) 0.375
Voltage (2H) 12.0
Fuel Type Gas
Regulator Included Yes
Terminal Type Blade
Gasket or Seal Included Yes
Terminal Quantity 4
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 1
In Tank or External In Tank
Resistance Ohms Empty 180.0
Resistance Ohms Full 10.0
Internal Or External Strainer Internal
Average Current Draw (A) 10
Pump Type Electric

F2GZ9H307A, F2GZ9H307G, F2GZ 9H307 G,

DELPHI FG2076
MOTORCRAFT PFS1074
MOTORCRAFT PFS1068

FORD EDGE 2015-2019
LINCOLN NAUTILUS 2019
