HYUNDAI 311103L500, 311103L500DS, 311113L000 Electric Fuel Pump Assembly

Fuel Level Sender Assembly Included Yes
Vapor Pressure Sensor No
System Pressure 55 psi
Package Contents Fuel Pump Module Assembly w/Float Arm, Instruction Sheet
Outlet Outside Diameter (in) 0.313
Voltage (2H) 12.0
Fuel Type Gas
Regulator Included Yes
Maximum Pressure (PS) 58.0
Terminal Type Blade
Gasket or Seal Included Yes
Terminal Quantity 5
Lock Ring Included No
Terminal Gender Male
Strainer Included Yes
Inlet Type Strainer
Outlet Type Quick Connect
Outlet Quantity 2
In Tank or External In Tank
Resistance Ohms Empty 130.0
Resistance Ohms Full 4.0
Internal Or External Strainer External
Average Current Draw (A) 7
Average Flow Rating (GP) 33
Pump Type Electric

311103L500, 311103L500DS, 311113L000,

DELPHI FG1685

HYUNDAI AZERA 2006-2011
