FORD 3L2Z9H307DA, 3L2Z9H307DB, 3L2Z9H307DC, 3L2Z9H307DD Electric Fuel Pump Assembly

Description: Fuel Pump Module Assembly
Gaskets Included: Yes
Height (in): 9.3
Max Pressure Range (Psi): 130.5
Max Free Flow (Gph): 69.6
Resistance Empty (Ohms): 7
Resistance Full (Ohms): 138
Rheostat Range (Ohms): 7-138
Inlet Quantity: 1
Inlet Type: Quick Connect
Inlet Diameter (IN): 5/16
Outlet Quantity: 1
Outlet Type: Quick Connect
Outlet Diameter (IN): 3/8
Compatible Fuels: Flex / Gas
Wiring Harness Included: No
Hardware Included: Yes
Min Free Flow Rate (Gph): 60.3
Min Pressure Range (Psi): 79.8
Strainer Included: Yes
Pin Count: 8
Pin Shape: Round
Connector Shape: Round
Connector Gender: Male
Inline Pump: No
In Tank: Yes
Negative Ground: Yes
Pump Type: Turbine
Volts: 12 vDC

FORD 3L2Z9H307DA, 3L2Z 9H307 DA, 3L2Z9H307DB, 3L2Z 9H307 DB, 3L2Z9H307DC, 3L2Z 9H307 DC, 3L2Z9H307DD, 3L2Z 9H307 DD,

SPECTRA PREMIUM SP2350M
DELPHI FG0864
AIRTEX E2350M
BOSCH 67190
CARTER P76157M
