068-903-803, 068-903-803A, 068903803, 068903803A for MERCEDES-BENZ Voltage Regulator

For 28mm OD slip ring
A-Circuit
Voltage Set Point 14.4v
W/Resistor
Hermetically sealed circuit

132980
IB355-1
(Ref# 35-9103)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, 14.5 Vset, 120 ohm Resistor
For: Bosch IR/EF Alternators
Used On: (1995-73) Audi, Hyundai, Mercedes, Mitsubishi, Peugeot, Porsche, Saab, VW, Volvo
Replaces:Audi, VW 068-903-803, 068-903-803A, 068903803, 068903803A BMW 12-31-1-279-548, 12311279548 Bosch 1197311003, 1-197-311-003, 1 197 311 003, 1197311007, 1-197-311-007, 1 197 311 007, 1197311008, 1-197-311-008, 1 197 311 008, 1197311009, 1-197-311-009, 1 197 311 009, 1197311022, 1-197-311-022, 1 197 311 022, 1197311023, 1-197-311-023, 1 197 311 023, 1197311035, 1-197-311-035, 1 197 311 035, 1197311050, 1-197-311-050, 1 197 311 050, 1197311800, 1-197-311-800, 1 197 311 800, 2197311022, 2-197-311-022, 2 197 311 022, 2197311023, 2-197-311-023, 2 197 311 023, Fiat 8194971, Ford E2HF-10304-BA, E2HZ-10304-A, E9DF-10304-AA, E2HF10304BA, E2HZ10304A, E9DF10304AA Hyundai 37370-21200, 3737021200 Lucas 21221438, UCB421, Mercedes-Benz 002-154-41-06, 002-154-51-06, 002-154-72-06, 0021544106, 0021545106, 0021547206 PSA Peugeot CITROEN 576147, 576155, 576159, 9405761558, Saab 85-59-619, 8559619, 85-71-846, 8571846, 85-90-549, 8590549, Volvo 1323467, 1324617, 1348322-7, 13483227, 3523710, 3523710-6, 35237106
Unit Nos: Bosch 0-120-468-009 to -012, -015, -016, -035, -036, -045, -046, -059, 0-120-469-543, 0-120-469-544, 0-120-469-547, 0-120-469-548, 0-120-469-555, 0-120-469-557, 0-120-469-563, 0-120-469-564, 0-120-469-567, 0-120-469-568, 0-120-469-583, 0-120-469-584, 0-120-469-588, 0-120-469-589, 0-120-469-608, 0-120-469-609, 0-120-469-611, 0-120-469-620, 0-120-469-628, 0-120-469-642, 0-120-469-644, 0-120-469-645, 0-120-469-664, 0-120-469-665, 0-120-469-668, 0-120-469-669, 0-120-469-670, 0-120-469-680 to -685, 0-120-469-680 to -744, 0-120-469-680 to -745, 0-120-469-680 to -746, 0-120-469-680 to -785, 0-120-469-680 to -786, 0-120-469-680 to -787, 0-120-469-680 to -793, 0-120-469-680 to -811, 0-120-469-680 to -812, 0-120-469-680 to -881, 0-120-469-680 to -882, 0-120-469-680 to -883, 0-120-469-680 to -896, 0-120-469-680 to -897, 0-120-469-680 to -927, 0-120-469-680 to -928, 0-120-469-680 to -935, 0-120-469-680 to -943, 0-120-469-680 to -945, 0-120-469-680 to -946, 0-120-469-680 to -947, 0-120-469-680 to -948, 0-120-469-680 to -992, 0-120-469-680 to -993, 0-120-488-120 to -122, 0-120-489-025, 0-120-489-026, 0-120-489-061, 0-120-489-064, 0-120-489-065, 0-120-489-066, 0-120-489-069, 0-120-489-070, 0-120-489-078, 0-120-489-079, 0-120-489-149, 0-120-489-150, 0-120-489-183, 0-120-489-184, 0-120-489-189, 0-120-489-190, 0-120-489-232, 0-120-489-233, 0-120-489-234, 0-120-489-242, 0-120-489-243, 0-120-489-253, 0-120-489-254, 0-120-489-258, 0-120-489-259, 0-120-489-274, 0-120-489-275, 0-120-489-286, 0-120-489-296, 0-120-489-310, 0-120-489-311, 0-120-489-323 to -328, 0-120-489-323 to -330, 0-120-489-323 to -354 to -358, 0-120-489-323 to -354 to -395, 0-120-489-323 to -354 to -396, 0-120-489-323 to -354 to -404, 0-120-489-323 to -354 to -405, 0-120-489-323 to -354 to -451, 0-120-489-323 to -354 to -452, 0-120-489-323 to -354 to -466, 0-120-489-323 to -354 to -881, 0-120-489-323 to -354 to -882, 0-120-489-323 to -354 to -917, 0-120-489-323 to -354 to -918, 0-120-489-323 to -354 to -928, 0-120-489-323 to -354 to -930, 0-120-489-323 to -354 to -932, 0-120-489-323 to -354 to -933, 0-120-489-323 to -354 to -935, 0-120-489-323 to -354 to -936, 0-120-489-323 to -354 to -971, 0-120-489-323 to -354 to -972, 0-120-489-323 to -354 to -974, 0-120-489-323 to -354 to -975, 0-120-489-323 to -354 to -997, 0120468009, 0120468010, 0120468011, 0120468012, 0120468015, 0120468016, 0120468035, 0120468036, 0120468045, 0120468046
Lester Nos: 13023, 056, 119, 122, 129, 153, 154, 156, 235, 243, 244, 281, 291, 363, 367, 379, 603, 604, 607;14059, 392, 412, 418, 420, 421, 595, 603, 783, 784, 785, 791, 802, 820, 824, 876, 964, 965, 966
Dim: 28mm Dia. Slip Ring
Features:
Hermetically sealed circuit
Silver plated trio terminal

AIRTEX / WELLS 1V1321
BERU GER022, GER005
HELLA 5DR 004 246-271 5DR004246271, 5DR 004 241-121 5DR004241121, 5DR 004 241-131 5DR004241131
HITACHI 130514, 2500514, 130504, 2500504
METZGER 2390017, 2390016
STELLOX 06-71671-SX 0671671SX
TRUCKTEC AUTOMOTIVE 07.17.008 0717008, 02.17.005 0217005
WAIglobal IB355
AINDE B-196 B196
ALANKO 700226
AS-PL ARE0003, ARE0016
BOSCH 1 197 311 003 1197311003
CASCO CRE10116AS
ERA 215263
HERTH+BUSS ELPARTS 35000143
JP GROUP 1190200900, 1190200902
LAUBER CQ1010629
MAGNETI MARELLI 940016002200
MESSMER 215263
MOBILETRON VR-B196M VRB196M
PATRON P25-0006 P250006
PowerMax 1111538, 81111538
SANDO SRE10116.0 SRE101160

MERCEDES-BENZ COUPE (C123) 1977/03 - 1985/12
MERCEDES-BENZ KOMBI Estate (S123) 1977/09 - 1986/12
MERCEDES-BENZ COUPE (C124) 1987/03 - 1993/05
MERCEDES-BENZ Saloon (W124) 1984/12 - 1993/06
MERCEDES-BENZ KOMBI Estate (S124) 1985/09 - 1993/07
MERCEDES-BENZ S-CLASS (W126) 1979/10 - 1991/06
MERCEDES-BENZ S-CLASS Coupe (C126) 1980/08 - 1991/06
MERCEDES-BENZ 190 (W201) 1982/10 - 1993/08
MERCEDES-BENZ CABRIOLET (A124) 1991/09 - 1993/06
MERCEDES-BENZ S-CLASS (W116) 1972/08 - 1980/07
MERCEDES-BENZ SL (R107) 1971/05 - 1989/12
MERCEDES-BENZ Saloon (W123) 1976/01 - 1985/12
MERCEDES-BENZ E-CLASS Coupe (C124) 1993/06 - 1997/06
MERCEDES-BENZ E-CLASS Convertible (A124) 1993/05 - 1998/03
