Delco 1116425, D683 Voltage Regulator

B-Circuit
P-L-I-S
Voltage Set Point 14.7V

133581
D425XHD
(Ref# 35-124)
Regulator
12 Volt, B-Circuit, P-L-I-S Terminals, 14.2 Vset, 2.5 sec. LRC
For: Delco CS130, CS144 Series IR/EF Alternators
Used On: (1999-89) Chevrolet, GMC;Chevrolet Truck, Freightliner, GMC Truck
Replaces: Delco 1116425, D683, Delco ASVR 19009724, Delco Electronics 16148399, DE125, Original Reference Number 125
(regulator
Servicing:CS130, CS144, 10479852, 10479959, 10479976, 10480022, 10480023, 10480088, 10480089, 10480093, 10480098, 10480156
stamped: 125, 425)
Unit Nos: Delco 1101478, 1101480, 1101482, 1101561, 1101566, 1101571, 1101806, 1101818, 1102605, 1102616, 1102635, 10479852, 10479959, 10479976, 10480022, 10480023, 10480062, 10480088, 10480089, 10480093, 10480098, 10480156, 10480192, 10480267, 10480269
Lester Nos: 7678, 7684, 7687, 7903, 7945, 7955, 7959, 7960, 7977, 8166, 8175, 8209, 8221, 8295
Note: Without temperature compensation
Features:
Heavy Duty ASVR Design
OE compliant functions
performance: current limiting, thermal
shutdown, load dump protection, shorted field
lamp circuit
protection
Welded construction - no solder joints for hi-temperature reliability
increased field life

ALANKO 700051
AS-PL ARE1016
WAIglobal D425XHD
MAGNETI MARELLI 940016041200
PowerMax 81116861

Delco CS 144 Alternators, RV, Industrial
