Delco Electronics 16191979, DE140 for TOYOTA Voltage Regulator

B-Circuit
P-L-I-S
Voltage Set Point 14.7V

233203
D440-1
(Ref# 35-128)
Regulator
12 Volt, B-Circuit, P-L-I-S Terminals, 14.7 Vset, 2.5 sec. LRC
For: Delco CS121 Series IR/EF Alternators
Used On: (1995-93) Geo, Toyota
Replaces: Delco 1116440, 440, Delco Electronics 16191979, DE140, Original Reference Number 140
(regulator stamped: 140, 440)
Unit Nos: Delco 1101626*, 10479805, 10480095, 10480096, Toyota 27060-02020, 27060-02050, 27060-02070, 27060-74200, 2706002020, 2706002050, 2706002070, 2706074200
Lester Nos: 8106, 8128
Note: *D440-1 regulator
46-1804 (DNM440) plug adapter will
replace the earlier design 3-terminal plug adapter w/ built-in circuitry
1116411 regulator.
Features:
Special circuit to handle extra load through the light circuit
Powers 6-dash lamps during key-on condition
Turns on through I-terminal
Use w/ 46-1804 (DNM440) connector or use D440G
Solves problem with OE weak circuit

ALANKO 700042
ERA 215106, 215105
MAGNETI MARELLI 940016041300
MESSMER 215105, 215106
PowerMax 81116121
WAIglobal D440

TOYOTA COROLLA Compact (_E10_) 1992/05 - 1999/11
TOYOTA COROLLA Liftback (_E10_) 1992/05 - 1997/04
TOYOTA COROLLA Wagon (_E10_) 1992/05 - 1997/04
TOYOTA CARINA E Saloon (_T19_) 1992/04 - 1997/09
TOYOTA CARINA E (_T19_) 1992/04 - 1997/09
TOYOTA CARINA E Sportswagon (_T19_) 1992/02 - 1997/09
TOYOTA CELICA (ST20_, AT20_) 1993/11 - 1999/11
TOYOTA COROLLA (_E10_) 1991/06 - 1999/11
TOYOTA COROLLA Wagon (__E11_) 1997/04 - 2001/10
