Delco 19009705, 19009729 Voltage Regulator for Buick

B-Circuit
P-L-F-S
Voltage Set Point 14.7V

231184
D705XHD
(Ref# 35-137)
Regulator
12 Volt, B-Circuit, P-L-F-S Terminals, 14.8 Vset, 10 sec. LRC
For: Delco CS130D Series IR/IF Alternators
Used On: (2003-95) Buick, Chevrolet, GMC, Isuzu, Oldsmobile, Pontiac
Replaces: Delco 19009705, 19009729, 705, Delco ASVR 19009729, 19009763, Original Reference Number 9729(regulator
Servicing:CS130D, 10480074, 10480076, 10480079, 10480184, 10480191, 10480207, 10480217, 10480218, 10480250, 10480251, 10480252
stamped: 705, 9729)
Unit Nos: Delco 10480074, 10480076, 10480079, 10480184, 10480191, 10480207, 10480217, 10480218, 10480250, 10480251, 10480252, 10480254, 10480259, 10480260, 10480289, 10480299, 10480301, 10480320, 10480321, 10480322, 10480332, 10480351, 10480353, 10480354, 10480361, 10480362
Lester Nos: 8190, 8197, 8199, 8222, 8223, 8224, 8228, 8229, 8230, 8231, 8233, 8240, 8275, 8276
Note: With temperature compensation.
Used on vehicles w/ digital instrument cluster.
Features:
Heavy Duty ASVR Design
OE compliant functions
performance: current limiting, thermal
shutdown, load dump protection, shorted field
lamp circuit
protection
Welded construction - no solder joints for hi-temperature reliability
increased field life

WAIglobal D705XHD
MAGNETI MARELLI 940016070800, 940016070300
ALANKO 700052
AS-PL ARE1033
CASCO CRE60110AS
ERA 215117
MESSMER 215117
PowerMax 81116706
SANDO SRE60110.0 SRE601100

Buick Skylark, Chevroet Cavalier,
Pontiac Grand-Am, Sunfire
