Ford VP3C3U-10C359-AA, VP3C3U10C359AA Voltage Regulator

F605
(Ref# 35-217)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, I-D-A Terminals
14.4 Vset, Gray w/ Green Cover
For: Ford 6G Series IR/IF Alternators
Used On: (2005-01) Ford
Replaces: Ford VP3C3U-10C359-AA, VP3C3U10C359AA
Unit Nos: Ford 1R3U-10300-AA, 1R3U-10300-AD, 1R3Z-10346-A, 2C3U-10300-BB, 2C3Z-10346-BA, 4C3Z-10346-AA, 1R3U10300AA, 1R3U10300AD, 1R3Z10346A, 2C3U10300BB, 2C3Z10346BA, 4C3Z10346AA
Lester Nos: 8266, 8316
Note: Regulator goes to Vsec (secondary regulation) and turns
on light with loss of sense (A).
With loss of light (I) connection, regulator continues to
function but vehicle indicator light does not turn on. Design
includes Field Current Limiting.
F605 is similar to F600 except:
F600: wo/ soft start feature
F605: w/ soft start feature
Components:
38-217-1 Brush
39-2702 Brush Spring
Features:
Soft start
Remote sense

AS-PL ARE9038
ERA 215186
MESSMER 215186
MOBILETRON VR-F901 VRF901
PowerMax 81116237
WAIglobal F605

FORD TRANSIT Bus (FD_ _, FB_ _, FS_ _, FZ_ _, FC_ _) 2000/01 - 2006/05
FORD TRANSIT Box (FA_ _) 2000/01 - 2006/05
FORD TRANSIT Platform/Chassis (FM_ _, FN_ _) 2000/01 - 2006/05
FORD USA MUSTANG Coupe 2004/12 - /
