Nissan 23215-50Y05, 2321550Y05 Voltage Regulator

A-Circuit
S-L
Voltage Set Point 14.3V

135027
IH760
(Ref# 35-8119)
Regulator
12 Volt, A-Circuit, S-L Terminals, 14.3 Vset
For: Hitachi IR/IF Alternators
Used On: (1991) Nissan
Replaces: Hitachi L170-33152, L170-33152, L17033152, L17033152, Nissan 23215-50Y05, 2321550Y05,
Unit Nos: Hitachi LR170-738, LR170-738B, LR170738, LR170738B, Nissan 23100-50Y06, 23100-50Y09, LR165-708, LR165-708B, 2310050Y06, 2310050Y09, LR165708, LR165708B, Lester Nos: 13334
WAI Ref. Nos: 1-1423-01HI
Note: With trio terminal.
Similar to IH761 except IH761 has stator terminal.
Components:
TRI760 Repair Circuit

ACDELCO E683
AIRTEX / WELLS 1V1240
ALANKO 700414
ASHIKA 77-01-125 7701125, 77-01-122 7701122
AS-PL ARE2014
CASCO CRE20117AS
ERA 215400
HITACHI 132853
JAPANPARTS RE-122 RE122, RE-125 RE125
JAPKO 77122, 77125
LAUBER CQ1010497
MDR MAR-9122 MAR9122, MAR-9125 MAR9125
MESSMER 215400
MOBILETRON VR-H2000-14 VRH200014
PARTS-MALL PXPBH-003 PXPBH003
PowerMax 1111426, 81111426
SANDO SRE20117.0 SRE201170
STANDARD VR490
WAIglobal IH760

NISSAN SUNNY II (N13) 1986/06 - 1991/10
NISSAN SUNNY II Coupe (B12) 1986/06 - 1991/06
NISSAN PRIMERA Traveller (W10) 1990/07 - 1998/03
