31150-PM5-0040, 31150PM50040 for ROVER Voltage Regulator

A-Circuit
C-FR-IG-L
26mm ID
Voltage Set Point 14.5V

135064
IM273
(Ref# 35-8317)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, C-FR-IG-L Terminals, 14.5 Vset
For: Mitsubishi IR/IF Alternators
Used On: (1989-88) Honda
Replaces: Honda 31150-PM5-0040, 31150PM50040, Mitsubishi A866X13670, A866X22072, A866X13671, A866T38570, 13671 (regulator stamped: 13670)
Unit Nos: Mitsubishi A1T02291, A1T02292, A1T04892, A001T02291, A001T02292, A001T02292ZC, A001T04892, A001T04892ZC, A001T04991, A005T04092, A005T04292, A005T06291
Lester Nos: 13266
WAI Ref. Nos: 1-1017-01MI
Dim: 26mm ID Slip Ring Cover
Note: L-terminal is an output terminal.
Similar to IM839 except IM839 L-terminal is not output terminal.
Components:
TRI273 Repair Circuit

ALANKO 700374
AS-PL ARE5045
LAUBER CQ1010355
MOBILETRON VR-H2009-20 VRH200920
PARTS-MALL PXPBG-040 PXPBG040
PowerMax 1115590, 81115590
ASHIKA 77-0M-M273 770MM273
JAPANPARTS RE-M273 REM273
JAPKO 77M273
WAIglobal IM273

ROVER 200 Hatchback (XW) 1989/10 - 1995/10
ROVER CABRIOLET (XW) 1990/04 - 1999/11
ROVER 400 (XW) 1990/04 - 1995/04
ROVER 200 Coupe (XW) 1992/10 - 1999/06
