HONDA 3177203J, A866X31782 Voltage Regulator

A-Circuit
IG-C-L-FR
24mm ID
Voltage Set Point 14.5V

230260
IM850
(Ref# 35-8348)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, IG-C-L-FR Terminals, 14.5 Vset
For: Mitsubishi IR/IF Alternators
Used On: (2001-96) Acura, Honda
Replaces: Honda 31150-P2E-A01, Mitsubishi 3177203J, A866X31782, MOBILETRON VR-H2009-71, LESTER 13649, PIC 203410, VRH200971, LESTER13649
, PIC203410,
Unit Nos: Honda 31100-P2E-A01, 31100-P2E-A02, 31100-P73-A01, 31100P2EA01, 31100P2EA02, 31100P73A01, Mitsubishi A5TA0991, A5TA09ZC, A5TA3591, Mitsubishi Motors ME10997D
Lester Nos: 13649, 13762
WAI Ref. Nos: 1-2094-01MI, 1-2195-01MI
Dim: 24mm ID Slip Ring Cover
Note: For stator activated version use IM853.
Features:
Trio activated

MOBILETRON VR-H2009-71 VRH200971
AIRTEX / WELLS 1V1023
STANDARD VR557
STELLOX 06-71713-SX 0671713SX
WAIglobal IM850
PowerMax 1116638, 81116638

HONDA
CIVIC 1.6L L4 1996
1.6L L4 SOHC 1997
CIVIC DEL SOL 1.6L L4 DOHC 1996
1.6L L4 SOHC 1996
ACURA INTEGRA 1.8L L4 1997 1998 2000 2001
