Kia 37370-22200, 3737022200 Voltage Regulator
VRT1483 Voltage Regulators
A-Circuit
S-L
Voltage Set Point 14.5V
S-L
Voltage Set Point 14.5V
138204
IY058
(Ref# 35-8604)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, S-L Terminals, 14.5 Vset
For: Mando 90A IR/IF Alternators
Used On: (2001-97) Hyundai
Replaces: Kia 37370-22200, 3737022200 Mando TA500C02401, AB190058, WIEGEL RGLMD520005
Unit Nos: Hyundai 37300-22200, 3730022200 Mando AB190058, AB190147, TA000A14501
Lester Nos: 13702
WAI Ref. Nos: 1-2059-01MD
Components:
TRI058 Repair Circuit
Features:
Trio activated
IY058
(Ref# 35-8604)
Regulator / Brush Holder Assy.
12 Volt, A-Circuit, S-L Terminals, 14.5 Vset
For: Mando 90A IR/IF Alternators
Used On: (2001-97) Hyundai
Replaces: Kia 37370-22200, 3737022200 Mando TA500C02401, AB190058, WIEGEL RGLMD520005
Unit Nos: Hyundai 37300-22200, 3730022200 Mando AB190058, AB190147, TA000A14501
Lester Nos: 13702
WAI Ref. Nos: 1-2059-01MD
Components:
TRI058 Repair Circuit
Features:
Trio activated
ALANKO 700192
AS-PL ARE9006
CASCO CRE32100AS
LAUBER CQ1010649
MAGNETI MARELLI 940016042100
MOBILETRON VR-H2009-86 VRH200986
PowerMax 1113385, 81113385
SANDO SRE32100.0 SRE321000
WAIglobal IY058
AS-PL ARE9006
CASCO CRE32100AS
LAUBER CQ1010649
MAGNETI MARELLI 940016042100
MOBILETRON VR-H2009-86 VRH200986
PowerMax 1113385, 81113385
SANDO SRE32100.0 SRE321000
WAIglobal IY058
