HONDA Voltage Regulator 31150-PE7-661, 31150-PE7-662, 31150PE7661

A-Circuit
Voitage Set Point 14.5V
63.5mm Mounting

132831
IN225
(Ref# 35-8212-2)
Regulator
12 Volt, A-Circuit, D-FR-IG-L Terminals, 14.5 Vset
For: Nippondenso IR/IF Alternators
Used On: (1991-85) Acura, Honda
Replaces: Honda 31150-PE7-661, 31150-PE7-662, 31150PE7661, 31150PE7662 Nippondenso 126000-0570, 126000-1350, 126000-0570, 126000-0344, USI 71-30009, MOBILLETRON VR-H2005-8, NEW ERA IVR-514J
Unit Nos: Honda 31100-PE7-660, 31100-PE7-661, 31100-PE7-662, 31100-PE7-663, 31100-PG7-013, 31100-PR4-A01, 31100-PR4-A02, 31100PE7660, 31100PE7661, 31100PE7662, 31100PE7663, 31100PG7013, 31100PR4A01, 31100PR4A02 Nippondenso 100211-135, 100211-137, 100211-393, 100211-732, 100211-733, 100211-1350, 100211-1351, 100211-1370, 100211-1371, 100211-2310, 100211-3880, 100211-7320, 100211-8610, 100211-8611, 100211135, 100211137, 100211393, 100211732, 100211733, 1002111350, 1002111351, 1002111370, 1002111371, 1002112310, 1002113880, 1002117320, 1002118610, 1002118611
Lester Nos: 13326, 14759, 14853, 14854, 14930
WAI Ref. Nos: 1-1000-01ND, 1-1002-01ND, 1-1905-01ND
Dim: 63.5mm Mtg. Length
Note: L-terminal is an output terminal.
Similar to IN429 except IN429 w/ LRC feature.
Components:
TRI225 Repair Circuit

ALANKO 700365
AS-PL ARE6005
BERU GER070
CASCO CRE40123AS
ERA 215654
HITACHI 132940
LAUBER CQ1010309
MAGNETI MARELLI 940016084000
MESSMER 215654
MOBILETRON VR-H2005-8 VRH20058
PowerMax 1114040, 81114040
SANDO SRE40123.0 SRE401230
WAIglobal IN057, IN225
ACDELCO E652, E632A
PARTS-MALL PXPBF-016 PXPBF016
STANDARD VR554

HONDA CIVIC IV Hatchback (EC, ED, EE) 1987/09 - 1993/10
HONDA CRX I (AF, AS) 1983/10 - 1987/10
HONDA CIVIC V Hatchback (EG) 1991/10 - 1995/11
HONDA CIVIC VI Coupe (EJ, EM1) 1996/03 - 2000/12
TOYOTA COROLLA Compact (_E9_) 1987/05 - 1995/10
TOYOTA COROLLA Coupe (AE86) 1983/05 - 1987/07
TOYOTA MR 2 I (AW1_) 1984/06 - 1990/06
TOYOTA CAMRY Saloon (_V1_) 1983/02 - 1988/07
TOYOTA CAMRY (_V2_) 1986/10 - 1993/02
TOYOTA CAMRY Liftback (_V1_) 1983/01 - 1988/01
TOYOTA CARINA II Saloon (_T15_) 1983/08 - 1988/05
TOYOTA CARINA II (_T15_) 1983/10 - 1988/05
TOYOTA CELICA Hatchback (ST16_, AT16_) 1985/08 - 1989/12
TOYOTA COROLLA FX Compact (E8B) 1984/08 - 1988/05
TOYOTA CELICA (AT16_, ST16_) 1985/08 - 1989/08
