Motorola Prestolite 8RH2002, 8RH2032, 8RH2026, 8RH2023 Voltage Regulator
VRT1711 Voltage Regulators
131175
M5-174A
Regulator
12 Volt, B-Circuit, 14.1 Vset
For: Motorola / Prestolite 8AL Series Alternators
Replaces: Motorola / Prestolite 8RH2002, 8RH2032, 8RH2026, 8RH2023, 8RH2006, 8RC2010A, 105-230, 105-, 105-174, 105-267
Unit Nos: Motorola / Prestolite 8AL2046F, 8AL2047F, 8AL2048F, 8AL2049K
Lester Nos: 7394, 7443
Terminal ID: Plug-Type E;Wiring Code 6
Orange Trio (+), Black Ground, Green Field, Yellow Ignition
Features:
Adjustable voltage
M5-174A
Regulator
12 Volt, B-Circuit, 14.1 Vset
For: Motorola / Prestolite 8AL Series Alternators
Replaces: Motorola / Prestolite 8RH2002, 8RH2032, 8RH2026, 8RH2023, 8RH2006, 8RC2010A, 105-230, 105-, 105-174, 105-267
Unit Nos: Motorola / Prestolite 8AL2046F, 8AL2047F, 8AL2048F, 8AL2049K
Lester Nos: 7394, 7443
Terminal ID: Plug-Type E;Wiring Code 6
Orange Trio (+), Black Ground, Green Field, Yellow Ignition
Features:
Adjustable voltage
WAIglobal M5-228A M5228A, M5-174A M5174A
